DC-DC Voltage Regulator Binghe Step Down Converter Buck Boost Converter Buck Converter with LCD Digital Display 5.5-30V to DC 0.5-30V Voltage Regulator Compatible with Arduino
DC-DC Voltage Regulator Binghe Step Down Converter Buck Boost Converter Buck Converter with LCD Digital Display 5.5-30V to DC 0.5-30V Voltage Regulator Compatible with Arduino
Description: Step down converter adopts lift off chip as main voltage regulator, external 60V 75A MOS tube as switching tube, dual 60V 5A SS56 Schottky for rectification, sufficient voltage resistance and sufficient power. On the LCD screen, input and output voltage, output current and output power can be displayed. Features: Built-in anti-reverse diode, so that the current will not reverse when the voltage exceeds the voltage of the module. The diode is also used as reverse polarity protection for the output. Parameters: Input voltage: 5.5-30 V (input voltage 5 V, can also be realized to increase and lower the voltage, but the voltage and current measurement is inaccurate; below 4.7 V, undervoltage protection). Output voltage: 0.5-30V. Output current: can work stably with 3A for a long time and can reach 4A with improved heat dissipation. Output power: natural heat dissipation 35 W, improved heat dissipation 50 W. Voltage display resolution: 0.01V 6. Current display resolution: 0.002A. Conversion efficiency: 88% or so. Soft start: yes (at very high power, the load module may fail at start) Protection against reverse polarity of the input: yes. Backflow prevention at output: yes. Short circuit protection: yes. Operating frequency: 180 kHz. Specification: Size: L x W x H 66 x 48 x 21 mm. Mounting hole: diameter: 4 mm. Weight: 46 g. Product includes: 1 x DC-DC step down converter.
Product Features
- Data visibility: the voltage regulator 12 V module is equipped with an LCD display that can display input and output voltage, output current and output power.
- Modularisation: the switching power supply can be used as a general lift module with overcurrent protection, step down converter as a charger and as a high-performance LED constant current driver module.
- Wide range of applications: boost, buck, output voltage 0.5-30 V arbitrarily adjustable, limit current 0-4 A arbitrarily adjustable. Voltage resolution is 0.01 V, current resolution is 0.002 A.
- Wide range of functions combined: Buck and booster functionality in one module that automatically switches between voltage raising and lowering. Step up converter Ideal for projects with varying input voltages.
- Powerful output: the buck boost converter delivers up to 3A output current to ensure a stable power supply, even with higher power requirements.
Original: $83.29
-65%$83.29
$29.15Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
DC-DC Voltage Regulator Binghe Step Down Converter Buck Boost Converter Buck Converter with LCD Digital Display 5.5-30V to DC 0.5-30V Voltage Regulator Compatible with Arduino
Description: Step down converter adopts lift off chip as main voltage regulator, external 60V 75A MOS tube as switching tube, dual 60V 5A SS56 Schottky for rectification, sufficient voltage resistance and sufficient power. On the LCD screen, input and output voltage, output current and output power can be displayed. Features: Built-in anti-reverse diode, so that the current will not reverse when the voltage exceeds the voltage of the module. The diode is also used as reverse polarity protection for the output. Parameters: Input voltage: 5.5-30 V (input voltage 5 V, can also be realized to increase and lower the voltage, but the voltage and current measurement is inaccurate; below 4.7 V, undervoltage protection). Output voltage: 0.5-30V. Output current: can work stably with 3A for a long time and can reach 4A with improved heat dissipation. Output power: natural heat dissipation 35 W, improved heat dissipation 50 W. Voltage display resolution: 0.01V 6. Current display resolution: 0.002A. Conversion efficiency: 88% or so. Soft start: yes (at very high power, the load module may fail at start) Protection against reverse polarity of the input: yes. Backflow prevention at output: yes. Short circuit protection: yes. Operating frequency: 180 kHz. Specification: Size: L x W x H 66 x 48 x 21 mm. Mounting hole: diameter: 4 mm. Weight: 46 g. Product includes: 1 x DC-DC step down converter.
Product Features
- Data visibility: the voltage regulator 12 V module is equipped with an LCD display that can display input and output voltage, output current and output power.
- Modularisation: the switching power supply can be used as a general lift module with overcurrent protection, step down converter as a charger and as a high-performance LED constant current driver module.
- Wide range of applications: boost, buck, output voltage 0.5-30 V arbitrarily adjustable, limit current 0-4 A arbitrarily adjustable. Voltage resolution is 0.01 V, current resolution is 0.002 A.
- Wide range of functions combined: Buck and booster functionality in one module that automatically switches between voltage raising and lowering. Step up converter Ideal for projects with varying input voltages.
- Powerful output: the buck boost converter delivers up to 3A output current to ensure a stable power supply, even with higher power requirements.
